Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift

Certification
Good quality Aluminum Work Platform for sales
Good quality Aluminum Work Platform for sales
"Its really a good handy machine working nicely. " The machine I am using in my mall, there are three four people came and see it in operation as well I expalin the machine usage and importance, may be they will contact you or me in future, I will let you know. -----Technical manager of Lucky One Mall in Pakistan.

—— Ehtesham Hussain

I'm Online Chat Now

Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift

China Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift supplier
Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift supplier Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift supplier Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift supplier

Large Image :  Aerial Work Platform With 136kg Load , 18 M Aluminum Alloy Personal Man Lift

Product Details:

Place of Origin: CHINA
Brand Name: SIVGE
Certification: CE
Model Number: GTWB18-4218

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: negotiation
Packaging Details: steel pallet with anti-rust covers
Delivery Time: 30-50 work days
Payment Terms: D/P, L/C, T/T
Supply Ability: 30 units per month
Contact Now
Detailed Product Description
Product Name: Aerial Work Platform With 136kg Load Quality Management System: ISO9001
Move Method: Powered Self-propeller Loading Capacity: 120kg
Material: Aluminum Alloy Color: According To Your Request

18 m aluminum alloy one man lift / aerial work platform with 136kg load





1. CE certificated.
2. Suitable for one persons work on
3. Best quality and performance
4. Good reliable after-sales service



Specification

18 m aluminum alloy one man lift / aerial work platform with 136kg load



Brand

SIVGE

Model

GTWB18-4218

Max. Platform Height

18m

Max. Working Height

20m

Loading Capacity

136kg

Number Of Person Allowed

1

Platform Dimension (mm)

1480*860

Outrigger Footprint (mm)

3140*2930

Power Supply

AC220V/50Hz

Power Input(kw)

AC:0.75/1.5kw

Move method

motor-propelled

Stowed Dimension (mm)

2360*1250*2180

Machine Weight (kg)

About 2150



Optional function:

1. Move method can be manual push type or motor-propelled;

2. special specification or design service offered.



If the above specification can not fulfill your working site, such as machine length, width and height, please contact us for further design service or non-standard models.



Standard features

  • Dual controls operation
  • Compact size with easy quick guardrail assemblage
  • Emergency stop buttons at both controls
  • Double emergency lowering device in case of power supply failure
  • 24V safe control voltage
  • Overload limit
  • Double safety protection with leveling stabilizers and outriggers support
  • Forklift pocket
  • Tilt audible alarm
  • Motor-propelled moving only stowed state
  • Low maintenance requirements will save you time and money.

Material & Design advantages

  1. Electrical components (such as buttons, key switch) that appear to the air are water-proof type with IP54
  2. Lifting limit switch is a key component for machine safety; we choose the more reliable brand OMRON.
  3. Original hydraulic system (including pump, motor and valves): Italy.
  4. Adopt international high-class hydraulic seals, Origin: Germany
  5. Patented guide roller device (installed within the masts) make the masts cooperate smoothly without clearance between them and the platform ascending and descending stably.
  6. The hydraulic pipe that we use is steel pipe (even we use hammer to hit against the pipe, the pipe will not break with oil leakage) while others usually use hose which is easy for leaking and damage by hit or during usage.
  7. Ratchet wheel swing handle of thread support bolts, easy to adjust for achieving precise leveling of the platform.
Packaging & Shipping
  • steel pallet with anti-rust covers
  • Open top container is in need
  • Delivery time is usually 45 days according to order qty. and models.
