Aluminum Alloy 8m Self Propelled Scissor Lift With 800mm Extension Platform

China Aluminum Alloy 8m Self Propelled Scissor Lift With 800mm Extension Platform supplier
Aluminum Alloy 8m Self Propelled Scissor Lift With 800mm Extension Platform supplier Aluminum Alloy 8m Self Propelled Scissor Lift With 800mm Extension Platform supplier

Large Image :  Aluminum Alloy 8m Self Propelled Scissor Lift With 800mm Extension Platform

Product Details:

Place of Origin: CHINA
Brand Name: SIVGE
Certification: CE / SGS / ISO9001
Model Number: GTWZ8-4008

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: wooden case or steel pallet, 4 units per 20GP
Delivery Time: 7-50 work days
Payment Terms: T/T, L/C, D/P, D/A
Supply Ability: 30 units per month
Contact Now
Detailed Product Description
Name: Hydraulic Boom Lift Platform Size: 1765*870*1100mm
Working Height: 10.0m Capacity: 400kg
Main Material: Aluminum Alloy Extension Platform: 800mm



8m self propelled electric lift table / scissor lift with 800mm extension platform


Mobile elevaitng work platform

widely used to workshop building site, hotel, airport, station, dock, palaestra, shoping malls, factory, plant and so on.

Mainly used to installing, repairing and cleaning high aerial equipment,power equipments, overhead pipeline and so on. It is an ideal equipment for guaranteeing working safe, improving working efficiency and making aerial working more convenient and quick.




Product standard features

  • Self-drive system for on site maneuvering from platform at full height

  • One hand proportional joystick

  • AC inverter motor drive

  • Drive speed interlock

  • Tilt level sensor with audible alarm

  • Overload limit

  • Emergency stop buttons at both controls

  • Emergency lowering device in case of power supply failure

  • Battery charger indictor

  • Forklift pocket

  • Compact size with easy quick guardrail assemblage system

  • Roll-out deck extension keeps everything you need within arm’s reach
  • Power source - 24V (four 12V/120 AH batteries*6)
  • Compact dimensions for space efficient storage.


Specification

8m self propelled electric lift table / scissor lift with 800mm extension platform



Brand SIVGE
Model-Code GTWZ8-4008
Max. Platform Height 8m
Max. Working Height (m) 10m
Loading Capacity (kg) 400
Number Of Person Allowed 2 persons
Platform Dimension (mm) 1760×860
Horizontal Extension (mm) 800 (optional)
Rated load for extension (kg) 100(optional)
Power Supply DC24V&DC48V
Motor

For Lifting (kw): 2.2 For traveling (kw): 3.0

Traveling speed (km/h)

Stored state: 2.5

Lifted state: 0.8

Min. swerve radius (m) 2.5
Stowed Dimension (mm) L×W×H: 2430×1150×1980
Machine weight about(kg) 2450

  • rated load for extenson: 100kg
  • Optional funtion: horizontal extension platform for 800mm at one side;

If the above specification can not fulfill your working site, such as machine length, width and height, please contact us for further design service.



Packing & Shipping


LCL: plywood case with steel pallet at bottom

FCL: steel pallet with anti-rust covers     20GP container for 4 set

Delivery time is usually 40 days according to order qty. and models.





After-sale Service

  • To provide a lifetime goods services for all Sivge equipments, included equipment maintenance, spare parts supply, provide manuals and video,etc.
  • To provide remote service support by phone and network freely.
