Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift

China Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift supplier
Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift supplier Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift supplier Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift supplier Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift supplier

Large Image :  Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift

Product Details:

Place of Origin: China
Brand Name: SIVGE
Certification: CE/ISO9001/ISO14001/OHSAS18001
Model Number: GTWR4-1004/ GTWR6-1006/ GTWR8-1008

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: USD 2000- 4000 / Units
Packaging Details: Standard
Delivery Time: 7-20 working days
Payment Terms: D/P, L/C, T/T
Supply Ability: 2000 units per month
Contact Now
Detailed Product Description
Name: Mobile Elevated Work Platform Max.working Height: 6/8/10/12 Meter
Capacity: 160kg Platform Size: 1200*600mm
Color: Customized Optional: DC / AC





Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift





R10 single mast 6-10m.pdf



Using purpose:

  1. Business decoration
  2. ceiling/fixture works
  3. industrial facilities maintenance,
  4. lamps and lanterns replacement in halls
  5. maintenance of street lamp
  6. aerial photographs
  7. wall cleaning etc.





Specifications



6 m Aluminum Alloy vertical mast lift single mast lift vertical platform lift aerial work platform manlift



Manufacturer SIVGE
Country of origin China
Model GTWR4-1004/ GTWR6-1006/ GTWR8-1008
Max. Working height 6/ 8/ 10 m
Max. Platform height  4 /6/ 8m
Platform capacity 300kg
Platform dimension L1200×W600
Stored height 1960mm
Stored length 2550mm
Stored width 1100mm
Machine weight about 720kg
Power supply

 DC24V with rechargeable battery

Power input 1.2kw
Dual control Platform and base control
Standard EN280



Display case



 Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift



Customized 6 -12 m Aerial mast Lift Platform hydraulic platform lift



Product features

  •  Overload limitation
  •  Dual control operation
  •  Double safety protection with leveling stabilizers and outriggers support
  •  Compact design with easy quick guardrail assemblage
  •  Emergency stop buttons at both controls
  •  No-marking tyre
  •  Emergency lowering device in case of power supply failure
  •  24V DC battery
  •  Hoist points at four corners
  •  The hydraulic pipe that we use is steel pipe (even we use hammer to hit against the pipe, the   pipe will not break with oil leakage) while others usually use hose which is easy for leaking   and damage by hit or during usage.
  •  Mast cover: PU mast cover protects the masts from dusts, and will not hurt your fingers which   the steel cover cannot achieve.
  •  Conform to EN 280:2013



Safe & Reliable

Safety is the main concern of SIVGE.

Professional & Innovative



SIVGE technical team has research and development the aerial work platforms for 20 years, especially mast platforms. We obtain dozens of patents and apply these patents to our machines.


We focus on portable aerial work platform, lifting mechanism synchronization, machine stability, operator comfort, and control of advanced, outriggers rationality, pleasant appearance, user reliability, complete varieties and specifications and other aspects to create a unique brand.

Sivge has build the national standards in aerial work platform fields, establishde High-tech R&D center.  build the National key scientific and technological support projects industrial base.





Packing &Shipping


LCL: plywood case with steel pallet

FCL: steel pallet with anti-dust cover

Delivery time is usually 30 days after order comfirmation.



Using purpose:

  1. Business decoration
  2. ceiling/fixture works
  3. industrial facilities maintenance,
  4. lamps and lanterns replacement in halls
  5. maintenance of street lamp
  6. aerial photographs
  7. wall cleaning etc.

Safe & Reliable

Safety is the main concern of SIVGE.

Professional & Innovative



SIVGE technical team has research and development the aerial work platforms for 20 years, especially mast platforms. We obtain dozens of patents and apply these patents to our machines.


We focus on portable aerial work platform, lifting mechanism synchronization, machine stability, operator comfort, and control of advanced, outriggers rationality, pleasant appearance, user reliability, complete varieties and specifications and other aspects to create a unique brand.

Sivge has build the national standards in aerial work platform fields, establishde High-tech R&D center. build the National key scientific and technological support projects industrial base.





Packing &Shipping


LCL: plywood case with steel pallet

FCL: steel pallet with anti-dust cover

Delivery time is usually 30 days after order comfirmation.
