Mini Scissor Lifts 6 Meter Working Platform For Painting

Basic Information
Place of Origin: China
Brand Name: SIVGE
Certification: CE / ISO / SGS / KCS
Model Number: ZS60
Minimum Order Quantity: 2 Unit
Price: USD 5999-6999 Unit
Packaging Details: Standard
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 20000
Detail Information
Type: Self Propelled Scissor Lifts Working Height: 6 Meter
Platform Height: 3.9 Meter Lift Capacity: 250 Kg
Overall Width: 0.76 M Platform Size: 0.7 X1.27 M
Battery: 24V/80AH Overall Length: 1.44 M
High Light:

6M Height Scissor Working Platform


6M Height Mini Scissor Lifts


250kg Load Mini Scissor Lifts

Product Description

Superior mini scissor lifts 6 meter working platform for painting


Electric Drive Self Propelled Scissor Lift is equipped with two kinds of motors, hydraulic lifting motor and electric driving motor. Hydraulic lifting motor supply power to lift up and down smoothly. Electric driving motor supply power to move forward, backward, turn around. Working Principle is different from hydraulic drive self-propelled scissor lift.

Electric Motor Drive Self Propelled Scissor Lift moves and lifts all by battery power. The operator can control lifting, moving, turning and all movement on the platform through the control system.



Standered configuration
● Proportion control
● Charging protection
● Automatic brake
● Tilt sensor alarm
● Fault diagnosis
● Energency stop
● Emergency lowering
● Pothole protection
● Foldable guardrails
● Extendable platform
● Bio-reducible hydraulic
● Flashing beacon
● Hour meter
● Self-lock gate
● Horn
● Action buzzer
● Safety Bracket
● Trackless tire
Main Features:
* The latest DTC control system with fault diagnosis system and voice guide.
* Hydraulic driving with balance valve, travel brake is more stable.
* With optional configuration of DC power drive, battery life is longer.
* Equipped with quick Charger, it is more time-saving and efficient.
* Double loading system, using efficiency of equipment is much improved.
* Centered scissor arm design, the comfort and stability of platform is improved.
* Higher working height with same numbers of scissor arms.
* Adopting electrophoresis coated, anti-corrosion performance triply improved



Download Brochure: Z series scissor lifts-Sivge-2019.pdf









Platform height

3.9 m

Working height

5.9 m

Load capacity


Table size

1.27*0.7 m

Machine weight

900 kg

Overall width

0.76 m

Stowed size

1.44*0.76*1.71 m

Driving mode

Self propelled

Lifting power

DC 24V


Product Description



Business decoration, ceiling/fixture works, industrial facilities maintenance, lamps and lanterns replacement in halls, maintenance of street lamp, aerial photographs and wall cleaning etc.




If the above specification cannot fulfill your working site, such as machine length, width and height, please contact us for further design service or non-standard models.


Mini Scissor Lifts 6 Meter Working Platform For Painting 1




Mini Scissor Lifts 6 Meter Working Platform For Painting 2


Mini Scissor Lifts 6 Meter Working Platform For Painting 3
