Single Mast Truck Mounted Aerial Lift Hydraulic Aluminium Alloy Aerial Work Platform

Basic Information
Place of Origin: China
Brand Name: SIVGE
Certification: CE/ISO9001/ISO14001/OHSAS18001
Model Number: GTWY8-1008T
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: 7 units per 20GP with steel pallets; plywood case for LCL
Delivery Time: 15-30 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 100 units per month
Detail Information
Product Name: Vehicle Mounted Boom Lift Application: Window Cleaning
Max.working Height: 10 Meter Rated Load/capacity: 136kg
Size Of Platform: 630*650mm Stowed Dimension: 2200*1100*2200mm
High Light:

Truck Mounted Man Lift


Truck Mounted Work Platform

Product Description



Hydraulic aluminium alloy truck-mounted lift / single mast aerial work platform



Occasions suitable to use this machine:


Using purpose:

Business decoration, ceiling/fixture works, industrial facilities maintenance, lamps and lanterns replacement in halls, maintenance of street lamp, aerial photographs and wall cleaning etc.



Places may in need of this kind of machine:


Warehouses, factories, museums, auditoriums, hotels, gymnasium, business/convention center, airports, auto stations and highway toll station etc.


Specifications of

Hydraulic aluminium alloy truck- mounted lift / single mast aerial work platform



Manufacturer SIVGE
Country of origin China
Model GTWY8-1008T, single mast
Max. Working height 10.0m
Max. Platform height 8.0 m
Platform capacity 136kg
Platform dimension L630×W650
Stored height 2220mm
Stored length 1100mm
Stored width 2220mm
Machine weight about 520kg
Power supply


with rechargeable battery

Power input DC:0.7kw
Dual control Platform and base control
Standard EN280


product photos as below


Single Mast Truck Mounted Aerial Lift Hydraulic Aluminium Alloy Aerial Work Platform 0


Product features

  •  Dual controls operation
  •  Compact design with easy quick guardrail assemblage
  •  Emergency stop buttons at both controls
  •  Emergency lowering device in case of power supply failure
  •  24V safe control voltage
  •  Overload limit
  •  Double safety protection with leveling stabilizers and outriggers support
  •  Hoist points at four corners
  •  Low maintenance requirements will save you time and money.
  •  Conform to EN 280
  • Patented guide roller device (installed within the masts) make the masts cooperate smoothly without clearance between them and the platform ascending and descending stably.
  • The hydraulic pipe that we use is steel pipe (even we use hammer to hit against the pipe, the pipe will not break with oil leakage) while others usually use hose which is easy for leaking and damage by hit or during usage.
  • Mast cover: PU mast cover protects the masts from dusts, and will not hurt your fingers which the steel cover cannot achieve.

Single Mast Truck Mounted Aerial Lift Hydraulic Aluminium Alloy Aerial Work Platform 1

Safe & Stable

User's safety is the basic concern point of SIVGE.

Professional & Innovative

The only thing SIVGE technical team has done in the past 20 years is research on the aerial work platforms, especially mast platforms. Each SIVGE innovation is the effort of our employees. We obtain dozens of patents and utilize these patents in our products.

SIVGE is focus on portable mobile elevating work platforms, lifting mechanism synchronization, outriggers rationality, machine stability, operator comfort, and control of advanced, pleasant appearance, user reliability, complete varieties and specifications and other aspects to create a unique brand.

Sivge is the drafter for a number of national standards, equipped with High-tech R&D center. National key scientific and technological support projects industrial base.
